• 4 sq. inch display
• Blue backlight
• Glow in the dark light button
• Easy access battery compartment
• Electric or Gas configurable
• Seperate heating and cooling swing (cycle rate) adjustments
• Room temperature calibration adjustments
• 5 minute compressor delay protection (selectable on or off)
• Simple private label badge system
• Easy wire color coded terminal blocks
• Universal sub-base
• Mounts on wall or junction box
• Battery or 24v power
• 5 year warranty

The control temperature range

44˚F to 90˚F (7˚C to 32˚C)

Load rating

1 amp per terminal, 1.5 amp maximum all terminals combined

Display accuracy

± 1 °F

Swing (cycle rate or differential)

Heating is adjustable from 0.2°F to 2.0°F - Cooling is adjustable from 0.2°F to 2.0°F

Power source

18 to 30 VAC, NEC Class II, 50/60 Hz for hardwire (common wire)

Battery power from 2 AA Alkaline batteries

Operating ambient

32° to +105° (0° to + 41°C)

Operating humidity

90% non-condensing maximum

Dimensions of thermostat

4.7"W x 4.4"H x 1.1"D
